Balanced ripple depth for strong yet controlled visual impact
Great for feature walls, columns, ceilings, and retail interiors
Available in 304/316 with mirror, hairline, and PVD color finishes
Balanced 3D Wave Texture for Commercial & Hospitality Interiors
Medium ripple water wave stainless steel sheets offer a stronger 3D effect than fine ripple, while maintaining controlled reflection for practical commercial use. This pattern is commonly selected for feature walls, columns, ceilings, and branded interior spaces.
| Specification | Details |
|---|---|
| Pattern Type | Medium Ripple / Water Wave (moderate 3D effect) |
| Material Grades | 304 / 316 Stainless Steel (201 available for indoor economy projects) |
| Recommended Thickness | 0.8 – 2.0 mm (common: 1.0 / 1.2 / 1.5 mm) |
| Standard Sheet Sizes | 1219×2438 mm (4×8 ft) / 1219×3048 mm (4×10 ft) |
| Finishes | Mirror (8K), Hairline (HL), PVD Color, Anti-Fingerprint (optional) |
| Protection Film | PVC protective film available (laser-friendly option upon request) |
| Customization | Cut-to-size, finish/color selection, pattern intensity options |
Medium ripple delivers a noticeable wave effect that stands out under lighting, while remaining controlled enough for practical day-to-day commercial environments.
This pattern works well for both vertical and overhead applications, making it a common choice for retail fit-outs, hotel renovations, and commercial branding projects.
Suitable for common fabrication processes such as laser cutting, bending, and framing. For large installations, we recommend confirming direction and layout with samples.
| Parameter | Typical Range | Buyer Notes |
|---|---|---|
| Ripple Depth | 0.4 – 1.2 mm | Moderate depth provides a premium 3D look without excessive distortion |
| Wave Pitch | Medium spacing | Works well for both small and large visible areas |
| Back Surface | Flat (standard) / reinforced optional | Reinforcement can be used for certain mounting systems |
| Processing Method | Embossed / stamped | Stable and repeatable for commercial batch supply |
| Finish | Effect | Recommended Use |
|---|---|---|
| Mirror (8K) | Bright reflection with pronounced wave highlights | Feature walls, lobby panels, statement areas |
| Hairline (HL) | More practical look, reduced glare, easier maintenance | Columns, elevator surrounds, high-traffic interiors |
| PVD Color | Gold / Rose Gold / Black / Champagne / Bronze | Retail branding, hospitality interiors, decorative trims |
| Anti-Fingerprint (Optional) | Reduced smudging and easier cleaning | Touch-prone panels and public interiors |
| Item | Details |
|---|---|
| Surface Protection | PVC film + corner protection available |
| Export Packaging | Wooden pallet or export wooden case (seaworthy) |
| Shipping Options | Sea freight / Air freight |
| Trade Terms | EXW, FOB, CIF, CFR, DDP |
Medium ripple provides a more noticeable 3D wave effect and stronger light-play, while fine ripple is more subtle and minimalist. Medium ripple is often chosen for feature areas.
Hairline (HL) is often preferred for practical maintenance. Anti-fingerprint coating can also help reduce smudges in public interiors.
Yes. Medium ripple is suitable for batch supply. For best visual continuity, we recommend confirming pattern direction and approving samples before mass production.
316 stainless steel is recommended for coastal or higher corrosion risk environments.
Yes. Samples can be provided for finish, color, and texture approval before bulk orders.
