This series of nickel alloy seamless pipes and capillary tubes is engineered for demanding environments requiring extreme corrosion resistance, stable performance under high temperatures, and long-term material reliability. Manufactured with advanced cold-drawing and cold-rolling processes, these tubes offer exceptional structural integrity and surface precision, making them suitable for chemical processing, offshore engineering, energy systems, aerospace applications, semiconductor equipment, and precision medical devices.
Nickel-based alloy seamless tubes and precision capillary pipes are designed for industries where materials must withstand aggressive chemicals, high thermal loads, and demanding mechanical conditions. Using premium nickel alloy billets, the tubes are processed through high-precision cold rolling and cold drawing, resulting in exceptional dimensional stability and excellent inner surface cleanliness.
These materials—including Inconel, Hastelloy, Monel, and pure nickel—are widely recognized for their superior corrosion resistance in acid, chloride, and seawater media. All tubing undergoes strict inspections under an ISO 9001 quality management system and complies with ASTM, ASME, and international marine classification standards.
The product line supports custom wall thickness, non-standard sizes, ultra-thin capillaries, and specialty grades for specific project needs.
| Category | Size Range | Notes |
|---|---|---|
| Seamless Tube OD | 6 mm – 500 mm | Heavy-wall and thin-wall options |
| Capillary Tube OD | 0.2 mm – 6 mm | For micro-instruments & sensors |
| Wall Thickness | 0.05 mm – 40 mm | High-precision tolerance available |
| Maximum Tube Length | Up to 12 meters | Cut-to-length per client request |
| Coil Tubing | Up to 150 meters | Ideal for continuous systems |
| Delivery Condition | Annealed / Solution Annealed / Age-Hardened | Mechanical properties adjustable |
| Surface Finish | BA, EP, Polished, Pickled | Suitable for food-grade and high-purity applications |
Nickel 200 (UNS N02200) — ASTM B161 / B163
Nickel 201 (UNS N02201) — ASTM B161 / B163
Inconel 600 / 601 / 625 / 690 / 718
UNS: N06600 / N06601 / N06625 / N06690 / N07718
ASTM: B167 / B163 / B444 / B983
Hastelloy C-276 / C-22 / C-2000 / B-2 / B-3 / C-4 / G-30 / X
UNS: N10276 / N06022 / N06200 / N10665 / N10675 / N06455 / N06030 / N06002
Monel 400（N04400） — ASTM B165/B163
Monel K-500（N05500）
800 / 800H / 800HT / 825 / 925 / Alloy 20
UNS: N08800 / N08810 / N08811 / N08825 / N09925 / N08020
Nimonic 80A / 90 / Alloy 263 / Waspaloy
Haynes 188 / L-605
NILO 36 / 42 / K (Invar / Kovar)
All tubes follow ISO 9001, ASME, and various CCS / DNV / ABS classifications.
Imported automated production line, digital surface inspection, full-size tensile & hardness testing.
Supports:
Ultra-thin capillary tubes
Special lengths (up to 12 m)
Coil tubing up to 150 m
Non-standard alloy development
Common grades (600, 625, C-276, 400, 800) have sufficient stock for immediate shipment.
| Industry | Application Examples |
|---|---|
| Chemical & Petrochemical | High-acid piping, reactors, corrosion-resistant loops |
| Oil & Gas / Offshore | Subsea lines, high-pressure injection tubing |
| Aerospace | Hydraulic lines, fuel systems |
| Marine Engineering | Saltwater-resistant systems & structures |
| Electronics / Instrumentation | Precision capillary tubes, probe tubing |
| Medical | Micro-capillary channels, endoscopic instruments |
