O & H Tempers | 0.018–0.20 mm Thickness | 100–1600 mm Width | Custom Foil Rolls
Voyage Metal supplies 8021 aluminum foil for deep-forming, flexible packaging, laminate structures and industrial converting. Reference supply capability covers thicknesses from 0.018 to 0.20 mm and widths from 100 to 1600 mm, with customized specifications available for project review.
Temper, roll size, core diameter, surface requirement, pinhole criteria, documentation and packing can be reviewed according to the buyer's production process and final application.
The following ranges are intended as practical procurement references. Final temper, dimensional tolerance, roll construction, surface condition and inspection criteria should be confirmed before order placement.
| Item | Reference Supply | Buyer Notes |
|---|---|---|
| Alloy / Grade | 8021 | 8xxx-series wrought aluminum alloy used for foil products. |
| Temper | F, O, H12, H14, H16, H18, H19, H22, H24, H26, H28 or customized | O temper is an important option where soft condition and forming behavior are required. Final temper should match the downstream process. |
| Thickness | 0.018–0.20 mm (18–200 μm) or customized | Confirm actual thickness and tolerance rather than relying only on generic foil gauge descriptions. |
| Width | 100–1600 mm (3.94–62.99 in) or customized | Slit widths can be reviewed according to converter and production-line requirements. |
| Supply Form | Jumbo Roll / Slit Roll / Customized Roll | Roll configuration depends on width, thickness, equipment and packing requirements. |
| Core ID | 76 / 152 mm or customized | Confirm the required core before rewinding or slitting. |
| Roll Weight / OD | By order requirement or customized | Should be matched to handling capacity and unwinding equipment. |
| Surface | Bright / Matte / Specified Finish | Final surface depends on thickness, rolling route and downstream coating, printing or lamination requirements. |
| Processing | Slitting / Rewinding / Custom Roll Preparation | Processing is reviewed according to finished width, roll weight and buyer equipment. |
| MOQ | 1 MT | Final quotation depends on temper, dimensions, processing and packing. |
| Stock Lead Time | 3–5 working days | Applies to available stock. Customized or made-to-order material requires separate lead-time confirmation. |
| Documents | MTC / MTR / COA as required | State required documents in the RFQ or purchase order. |
| FDA / Testing | Documentation and testing available upon request | Applicable regulated-use requirements should be confirmed by final product structure, destination and intended use. |
| Packing | Export pallet / protective wrapping / customized | Moisture protection, roll protection and shipping marks can be discussed for export orders. |
8021 is an 8xxx-series wrought aluminum alloy with iron as a principal controlled alloying component. In foil form, it is commonly evaluated for applications where a combination of soft temper, forming capability, controlled thickness and stable converting performance is required.
For industrial purchasing, the alloy number alone is not enough to define performance. Buyers should specify the temper, thickness, width, tolerance, surface condition, pinhole requirement, roll configuration and end use.
Buyers comparing different foil grades can also review 8011 aluminum foil , 8079 aluminum foil and 1235 aluminum foil .
The registered alloy composition identifies 8021 aluminum. Batch chemistry for a specific shipment should be checked against the agreed material certificate and purchase specification.
| Element | 8021 Composition Limit | Engineering Note |
|---|---|---|
| Silicon (Si) | ≤ 0.15% | Registered alloy composition limit. |
| Iron (Fe) | 1.20–1.70% | Major controlled alloying component in 8021. |
| Copper (Cu) | ≤ 0.05% | Controlled residual/alloy limit. |
| Other Elements — Each | ≤ 0.05% | Per registered composition limits. |
| Other Elements — Total | ≤ 0.15% | Per registered composition limits. |
| Aluminum (Al) | Remainder | Balance of registered alloy composition. |
Temper identifies the metallurgical condition of the foil. The correct temper should be selected together with thickness, forming depth and the downstream converting process.
Annealed, soft condition commonly evaluated where higher ductility and forming capability are important.
Strain-hardened conditions used when a buyer requires a different balance of hardness, strength and forming behavior.
Strain-hardened and partially annealed conditions available for project-specific foil requirements.
Do not select temper only by alloy number. State forming, lamination, stiffness and downstream processing requirements.
Foil buyers often need more than an alloy and thickness. Roll configuration should match the converting line, handling method and finished-product process.
Pinhole behavior becomes increasingly important as foil becomes thinner. Sensitive barrier structures should therefore define an inspection method and acceptance level rather than relying only on alloy designation.
For more information on foil gauge and thickness selection, see our Aluminum Foil Thickness Guide .
State foil thickness, application, laminate structure, acceptable pinhole criteria, inspection method and any reporting requirement.
ASTM B926 pinhole inspection can be discussed where the buyer's specification requires this type of light-table test method.
Final suitability depends on alloy condition, thickness, forming depth, laminate or coating structure, regulatory requirements and the buyer's downstream production process.
8021 foil can be evaluated in applications requiring a soft foil condition and substantial forming during downstream package production.
Confirm temper, thickness, forming depth and laminate structure.8021 can be supplied as a base foil for selected pharmaceutical and cold-form packaging structures, subject to final laminate design, inspection criteria and applicable compliance requirements.
Final regulatory suitability is application-specific.Used as an aluminum layer in converted structures where foil is laminated, coated, printed or further processed by packaging converters.
Surface and pinhole requirements should be defined in the RFQ.8021 may be evaluated as part of selected laminated battery pouch structures where forming behavior is required.
This is different from aluminum current-collector foil used inside a battery cell.For a broader overview of foil end uses, see Industrial Aluminum Foil Uses: Packaging, Insulation, Electronics and Buying Tips .
Documentation requirements differ by application and destination market. Voyage Metal can provide material and compliance documentation according to the buyer's purchase requirement and can arrange project-specific testing when required.
For food-contact, pharmaceutical or other regulated applications, please state the final use, destination market, finished structure and required test/document standard in the RFQ.
These alloys should not be treated as interchangeable based only on price. The required temper, thickness and finished application determine which foil should be technically reviewed.
| Alloy | General Procurement Position | Typical Buyer Focus | Product Page |
|---|---|---|---|
| 8011 | Widely used general packaging foil alloy | Household, catering, container and flexible packaging requirements | View 8011 Foil |
| 8021 | Foil alloy evaluated for forming-intensive and converted structures | Soft temper, forming depth, laminate structure and pinhole criteria | Current Product |
| 8079 | Flexible packaging and thin-gauge converting alloy | Flexibility, roll quality, surface and packaging conversion | View 8079 Foil |
Alloy, temper, batch identification and required material documents.
Thickness, width and applicable dimensional requirements.
Surface appearance, edge condition, winding and agreed roll configuration.
Packing, labels, documents and project-specific inspection requirements.
A complete RFQ allows us to check availability and technical compatibility before preparing a quotation.
| Commercial Item | Voyage Metal Supply Term |
|---|---|
| Minimum Order Quantity | 1 metric ton |
| Available Stock | Shipment preparation / delivery arrangement normally 3–5 working days for available stock. |
| Customized Production | Please contact Voyage Metal for lead time based on temper, thickness, width, quantity and processing. |
| Material Documents | MTC, MTR, COA and buyer-required documents can be supplied according to order requirements. |
| Testing | FDA-related and other project-specific testing can be arranged according to the required application. |
| Export Packing | Roll protection, pallet packing, moisture protection and shipping marks according to order requirements. |
8021 is an 8xxx-series wrought aluminum alloy used in foil applications. Buyers commonly evaluate it where soft temper, forming performance, controlled thickness and converting requirements are important.
Reference temper options include F, O, H12, H14, H16, H18, H19, H22, H24, H26 and H28. Final availability should be confirmed by thickness, width, quantity and end use. O temper is an important option for forming-intensive applications.
The reference thickness range is 0.018–0.20 mm, or 18–200 microns. Customized thicknesses can be reviewed according to application, quantity and production capability.
The reference supply width is 100–1600 mm or customized. Finished slit width, width tolerance and roll configuration should be included in the RFQ.
8021 can be considered as a base foil for selected pharmaceutical and cold-form packaging structures. Final suitability depends on the finished laminate, thickness, forming requirement, coating or adhesive system, applicable regulations and required testing.
Yes. FDA-related documentation is available for applicable orders, and testing can be arranged according to customer and project requirements. Buyers should provide the final application and required compliance criteria before order confirmation.
8021 may be evaluated as the aluminum layer in selected battery pouch laminate structures. This application is different from battery current-collector foil, so the complete laminate and technical requirements should be confirmed before quotation.
The minimum order quantity is 1 metric ton. Final availability and quotation depend on temper, thickness, width, processing and packing.
Available stock can normally be arranged within 3–5 working days. Made-to-order or customized material requires a separate production lead-time confirmation.
MTC, MTR, COA and project-specific documents can be supplied according to customer requirements. State all required documents and testing in the RFQ or purchase order.
For a technically comparable quotation, please send: temper + thickness × width + tolerance + core ID + roll weight/OD + quantity + application + surface/pinhole requirement + required documents + destination.
